Fortigate VPN - Filter Debug logs

on

I'm in the process of debugging a failing site to site VPN from a FortiGate to a Cisco ASA. The Forti has in excess of 30 IPsec VPNs configured on it so issuing the standard cli command :


diagnose debug application ike -1
diagnose debug enable

Isn't particularly useful due to the volume of entries you'll get.

We want to filter it to one specific VPN so we do this instead:

diagnose vpn ike log filter name <phase1-name>
diagnose debug app ike -1
diagnose debug enable

Then you'll just get the entries relating to the VPN you want to work on.

This and a lot more useful stuff relating to troubleshooting VPN's can be found here:
https://docs.fortinet.com/document/fortigate/5.4.0/cookbook/168495
